Rawlplug R-S1-RBL-M10/75/5 Rawlbolt Loose Bolt M10/75L (Bag 5) RAWM1075LB

Name: Rawlplug R-S1-RBL-M10/75/5 Rawlbolt Loose Bolt M10/75L (Bag 5) RAWM1075LB
Brand: rawlplug
SKU: SKU-29c15a6d
Availability: InStock

Doors & Door Fittings

Currently Unavailable

Add Product to Wishlist

Description

These Rawlplug Rawlbolt(r) Loose Bolts have the following specification: Anchor Diameter: 10mm External Diameter: 16mm Length: 140mm Fixture Max. Thickness: 75mm Hole Diameter: 11mm Hole Diameter in Substrate: 16mm Installation Torque: 27 Wrench Size: 17 Min. Hole Depth in Substrate: 65mm Min. Installation Depth: 60mm Min. Substrate Thickness: 100mm Min. Spacing: 50mm Min. Edge Distance: 75mm Pack Quantity: Bag of 5 The Rawlplug Rawlbolt(r) Loose Bolt is suitable for use in cracked and non-cracked concrete (ETA option 1)
